New Adept ATR B and D Tablet Press
- 8 Stations
- (4) D and (4) B Tooling
- GMP
- Pre-compression
- 3 HP motor to meet your electrical requirements
- Output: up to 14,400 tablets/hr
- Maximum tablet diameter: 25mm D/18.5 mm B
- Maximum depth of fill: 18 mm
- Maximum operating pressure: 6 tons
- Machine dimensions: 63 x 86 x 120 cms
- Machine weight: 450 kgs
Optional stainless steel table with 2 drawers with locks: $1,500.00

New Adept ATR D 8 Station Tablet Press
- 8 stations
- D Tooling
- GMP
- Pre-compression
- 3 HP motor to meet your electrical requirements
- Output: up to 14,400 tablets/hr
- Maximum tablet diameter: 25 mm
- Maximum depth of fill: 18 mm
- Maximum operating pressure: 6 tons
- Machine dimensions: 63 x 86 x 120 cms
- Machine weight: 450 kgs
Optional stainless steel table with 2 drawers with locks: $1,500.00

New Adept model ADR 27 Station Double Sided Tablet Press
- D tooling
- Double keyed
- GMP model
- Knob controls for tablet weight and thickness
- A.C. speed variator
- Auto lubrication
- 5 HP, 1440 RPM motor

Maximum tablet diameter: 25 mm
Maximum tablets/hour: 97,200
Maximum fill depth: 17.5 mm
Maximum pressure: 10 tons
Machine dimensions: 42" x 43" x 63"

New Adept model ADR 35 Station Double Sided Tablet Press
- B tooling
- Double keyed
- GMP model
- Knob controls for tablet weight and thickness
- A.C. speed variator
- Auto lubrication
- 5 HP, 1440 RPM motor

Maximum tablet diameter (round): 18.5 mm
Maximum tablet diameter (caplet): 19 mm
Maximum tablets/hour: 159,600
Maximum fill depth: 17.5 mm
Maximum pressure: 10 tons
Machine dimensions: 42" x 43" x 63"

New Adept model ADR 45 Station Double Sided Tablet Press
- B tooling
- Double keyed
- GMP model
- Knob controls for tablet weight and thickness
- A.C. speed variator
- Auto lubrication
- 5 HP, 1440 RPM motor

Maximum tablet diameter (round): 13 mm
Maximum tablet diameter (caplet): 16 mm
Maximum tablets/hour: 205,200
Maximum fill depth: 17.5 mm
Maximum pressure: 10 tons
Machine dimensions: 42" x 43" x 63"

New Adept model ADR 59 Station Double Sided Tablet Press
- BB tooling
- Double keyed
- GMP model
- Knob controls for tablet weight and thickness
- A.C. speed variator
- Auto lubrication
- 5 HP, 1440 RPM motor

Maximum tablet diameter (round): 10 mm
Maximum tablets/hour: 269,040
Maximum fill depth: 17.5 mm
Maximum pressure: 6.5 tons
Machine dimensions: 42" x 43" x 63"

New CVC (Cremer) model 1220 High Speed Electronic Channel Counter
- 12 channels, each with an infrared sensor
- LD hand held terminal (Touch screen PC terminal optional)
- Infeed and outfeed track sensors
- Auto dust compensation with dual vacuum ports
- Count verification and rejection
- Stainless steel construction
- 50 job memory capacity
- Quick and simple change over

Tablet/capsule/soft gel width/diameter: 1/8" - 3/4"
Tablet/capsule/soft gel length: 1/8" - 1-3/16"
Bottle height: 1-1/2" - 7-3/4"
Bottle diameter: 3/4" - 4"
Capacity: Up to 55 bottles per minute on a 100 count fill

New CVC (Cremer) model 1620 High Speed Electronic Channel Counter
- 16 channels, each with an infrared sensor
- Can be set up to run one bottle using all 16 channels, or two bottles using 8 channels
- Touch screen PC terminal
- Infeed and outfeed track sensors
- Auto dust compensation with dual vacuum ports
- Count verification and rejection
- Stainless steel construction
- 50 job memory capacity
- Quick and simple change over

Tablet/capsule/soft gel width/diameter: 1/8" - 3/4"
Tablet/capsule soft gel length: 1/8" - 1-3/16"
Bottle height: 1-1/" - 7-3/4"
Bottle diameter: 3/4" - 4"
Capacity:
- Single bottle - up to 70 bottles per minute on a 100 count fill
- Double bottle - up to 100 bottles per minute on a 90 count fill

New CVC 100 Pressure Sensitive Labeler
- Rated at 105’ of label per minute
- Labelset system auto system
- Die cast labeling heads
- Label and product sensors
- Stainless steel construction
- Stepper motor drives for: label feed
- Mounted on portable stand
- Upgradable for future hot stamp install
- Vertical and horizontal adjustability
- Stepper motor drive

New CVC model 1103 Pouch Desiccant Inserter
- Stianless steel
- Cuts desiccant packets from a roll and inserts
- PLC driven & servo motor conrolled with 6" touchscreen terminal
- 10 job memory capacity
- Interlocked safety shield
- 1 - 5 pouch insertions per bottle
- Single phase, 50/60 cycles, 220 volts
- Up to 120 bottles/minute
- Pouch length: 1-3/16" - 2-3/8"
- Pouch width: 5/8" - 1"
- Bottle diameter: 1-1/4" - 4-1/4"
- Bottle height: 2" - 7-3/4"
- Bottle opening: 1" - 4-1/4"

New CVC model 1117 Cottoner
- Stainless steel
- Works with cotton polyester and rayon
- PLC driven & servo motor controlled with 6" touchscreen terminal
- 10 job memory capacity
- Interlocked safety shield
- Optional missing cotton reject system
- On casters with easy height adjustment
- Single phase, 50/60 cycles, 220 volts
- Up to 60 bottles/minute
- Strip length: 2-1/4" - 6"
- Bottle diameter: 1-1/4" - 4-1/4"
- Bottle height: 2" - 8-1/2"
- Bottle opening: 1" - 2"

New CVC model 1117-2 Dual Head Cottoner
- 2 cottoners mounted on a single frame
- Stainless steel
- Works with cotton, polyester and rayon
- PLC driven & servo motor controled with 6" touchscreen terminal
- 10 job memory capacity
- Interlocked safety shield
- Optional missing cotton reject system
- On casters with easy height adjustment
- Single pase, 50/60 cycles, 220 volts
- Up to 120 bottles/minute
- Strip length: 2-1/4" - 6"
- Bottle diameter: 1-1/4" - 4-1/4"
- Bottle height: 2" - 8-1/2"
- Bottle opening: 1" - 2"

New CVC model 1205 Capper With Cap Elevator
New CVC model 1205 8-spindle stainless steel capper mounted over a 14-ft sanitary platform chain conveyor, and with v shaped 9.1 cubic foot cap hopper elevator. This PLC controlled capper has an adjustable cap chute for running different sized caps without the need for change parts and has an inspection system for removing incorrectly oriented caps.
Optional rejection system for improperly capped bottles and/or missing foil cap liner available at additional charge.

- Stainless steel
- 8 spindles
- Siemens PLC controlled with 6" touch screen panel
- 9.1 cubic foot cap hopper elevator
- Adjustable cap chute
- Single phase, 50/60 cycles, 220 volts
- Up to 120 bottles per minute
- Cap diameter: 25 – 108mm
- Cap height: 13-19mm
- Bottle diameter: 32 – 114mm (190mm with a 6" conveyor)
- Bottle height: 51 – 216mm

New CVC model 1208 Cap Retorquer
- Stainless steel
- 2 spindles
- Siemens PLC controlled with 6" touch screen panel
- Single phase, 50/60 cycles, 220 volts
- Up to 120 bottles per minute
- Cap diameter: 28 – 111mm
- Cap height: 10 - 20mm
- Bottle diameter: 28 – 118mm
- Bottle height: 50 – 200mm

New CVC model 1265 Plastic Bottle Unscrambler
- Stainless Steel
- Automatically feeds bottles from a bin and places them upright onto a conveyor
-PLC driven with 6" touchscreen panel
- 10 job memory capacity
-Interlocked safety shield
-Optional ionized air rinse, fallen bottle sensor & low level hopper sensor
- 15 cubic foot hopper
- Single phase, 50/60 cycles, 220 volts
- Up to 200 bottles/minute
- Bottle diameter: 1-1/4" - 3-1/4"
- Bottle height: 2" - 6"
- Bottle opening: 1" - 3-1/4"

New CVC model 1267 Plastic Bottle Unscrambler
- Stainless steel
- Automatically feeds bottles from a bin and places them upright onto a conveyor
- PLC driven with 6" touchscreen panel
- 10 job memory capacity
- Interlocked safety shield
- Optional ionized air rinse, fallen bottle sensor & low level hopper sensor
- 24 cubic foot hopper
- Single phase, 50/60 cycles, 220 volts
- Up to 200 bottles/minute
- Bottle diameter: 1-1/4" - 5"
- Bottle height: 2" - 8"
- Bottle opening: 1" - 4-1/4"

New CVC model 200 Pressure Sensitive Top and Side Labeler
New CVC model 200 pressure sensitive top labeler mounted on a 52" long x 4" wide chain conveyor. These labelers come with CVC's patented selfset (tm) product set-up system, which generates initial settings for motor speed, bottle application timing and labeling position and displays product output and labels remaining.

- Mounted on a 52-1/4" long x 6" wide conveyor
- Patented SELFSET one touch auto adjusting set up
- Stainless steel frame
- Hand-held terminal with LCD display
- Lockable casters
- Single phase, 60 cycle, 110 volts
- Up to 200 labels per minute
- Product height: 1" - 7-1/4"
- Product width: 1" - 10"
- Product length: 1" - 11"
- Label height: 5/8" - 6"
- Label length: 5/8" - 10"

New CVC model 220 Pressure Sensitive Top and Bottom Labeler
New CVC model 220 top & bottom pressure sensitive labeler mounted on a 6" wide (10" also available) x 73" long belt conveyor with stainless steel frame on lockable casters. These labelers come with CVC's patented selfset (tm) product set-up system, which generates initial settings for motor speed, bottle application timing and labeling position and displays product output and labels remaining.

- Mounted on a 55-1/2" long x 6" wide conveyor
- Patented SELFSET one touch auto adjusting set up
- Stainless steel frame
- Hand-held terminal with LCD display
- Lockable casters
- Single phase, 60 cycle, 110 volts
- Up to 200 labels per minute
- Product height: 1" – 7-1/4"
- Product width: 1" – 10"
- Product length: 1" - 16"
- Label height: 5/8" – 6"
- Label length: 5/8" – 10"

New CVC model 300 wraparound pressure sensitive labeler
- mounted on a 79" long x 4" wide stainless steel platform chain conveyor (also available with 94", 118", 138" & 158" long and 4-1/2" & 6" wide conveyors)
- patented SELFSET one touch auto adjusting set up
- stainless steel frame
- Servo motor with PLC controls
- lockable casters
- single phase, 60 cycle, 220 volts
Speed: up to 170/minute
Bottle height: 1" - 12"
Bottle diameter" 1" - 7"
Label height: 3/8" - 9"
Label length: 5/8" - 12"

New CVC model 302 wraparound pressure sensitive labeler mounted on a 121" long x 4" wide chain conveyor. It can be equipped with a bar code verification, hot stamp code verification and automatic rejection system. The labeling head is servo motor powered for increased speed and accuracy and is equipped with a touch screen control, which is programmed in English, Spanish and Chinese. These labelers come with CVC's patented selfset (tm) product set-up system, which generates initial settings for motor speed, bottle application timing and labeling position and displays product output and labels remaining.

- Mounted on a 121" long x 4" wide stainless steel platform chain conveyor (6" wide also available)
- Patented SELFSET one touch auto adjusting set up
- Stainless steel frame
- Touchscreen HMI and servo motor with PLC controls
- Adjustable tilt for tapered bottles
- Lockable casters
- Single phase, 60 cycle, 220 volts
- Up to 250 bottles per minute
- Bottle height: 1" - 12"
- Bottle diameter: 1" - 7"
- Label height: 3/8" - 7"
- Label length: 1/2" - 12"
