Chocolate Equipment

Tinsley Belt Polisher model # TDF-74P

Tinsley Belt Polisher model # TDF-74P
:

This 74" belt polisher for a production output of 400 - 800 lbs./hour is constructed totally of stainless steel with a food grade polypropylene belt and sidewalls. Using a heated top scraper to return maximum of the chocolate from the belt surface back into the processed product.

Includes the following:
- Intralox Series 800 mat top belting with ribs, 76" wide, and complete with all necessary UHMWP carry-way support wear strips. Driven by a 3 HP motor, 1750 RPM, complete with the gearbox for a final output of 76 RPM, or a linear belt speed of up to 200-FPM max. Drive motor controlled via variable frequency speed controller for belt speed adjustment from 0 - 200 FPM. This will allow for excellent product tumble and uniform product polishing at its proper belt speed for the different products.

- The polishing liquid feed will be controlled by the solenoid rotating valve and through the spray nozzle manifold. The manifold will be hot water jacketed for good polishing liquid flow. The spray nozzles will be at approximately 15" centers, allowing a good & uniform product coating. This polisher will be equipped with 5 spray nozzles.

- A 5 gallon tank with piping and one pump for the polish & glazing feed will be included.

- To prevent product traveling with the belt, a retaining bar spaced about ¼" from the belt surface will scrape the product off the belt and drop it down to the other product area.

- An interior light will light up the product processing area for easy inspection during the processing.

- The air knife for cold air supply to cool & dry the product is designed to handle a typical 1700 CFM of cold air at 48 - 55 deg. F. External air chiller will be required. (Not included with machine.)

- An air / fume exhaust duct will be installed at the back side of the machine to remove any vapors from the polishing process. Air exhaust blower rated for 1700 CFM mounted on top of machine is included.

- Lexan front doors will allow for easy product access and inspection.

- Basic machine with PLC controls and wired for 480 Volts, 3 Ph., 60 Hz., with main disconnect

- Machine size and weight: 105" long x 76" deep x 86" height. Approximately 3,200 pounds total.

Tinsley Chocolate Melter, 100 - 20,000 lbs

Tinsley Chocolate Melter, 100 - 20,000 lbs.
New chocolate tanks in sizes from 100 to 20,000 lbs. in either carbon or stainless steel with electric immersion heaters and thermostats for water jacket. Temperature gauges for water and chocolate. Agitators with motor voltage to suit customers’ requirements. Other sizes are available upon request. Tanks are quoted with electrical starter boxes with on/off controls.

New Tinsley Stock Chocolate Melting/Holding Tanks with 3/60/220v electricals:

100lb stainless steel bottom drive
300lb stainless steel bottom drive
500lb stainless steel top drive
1,000lb stainless steel top drive
2,000lb stainless steel top drive
3,000lb stainless steel top drive
4,000lb stainless steel top drive
5,000lb stainless steel top drive

New Tinsley Non-Stock Chocolate Melting/Holding Tanks Made per Order:

500lb carbon steel top drive
500lb stainless steel bottom drive
1,000lb carbon steel top drive
1,000lb carbon steel bottom drive
1,000lb stainless steel bottom drive
1,300lb stainless steel top drive
2,000lb carbon steel top drive
2,000lb carbon steel bottom drive
2,000lb stainless steel bottom drive
2,000lb stainless steel top drive low profile
3,000lb carbon steel top drive
5,000lb carbon steel top drive
5,000lb horizontal stainless steel
7,500lb carbon steel top drive
7,500lb stainless steel top drive
10,000lb carbon steel top drive
10,000lb stainless steel top drive
20,000lb stainless steel top drive

Options:

Sanitary fittings threaded onto NPT pipe
UL approval on electrical panel
Lid interlock addition per side
Day-Night electrical controls
Stack light for agitator
Stainless steel electrical panel for standard size box
Upgrade to 480v electricals/panel
Water circulation pump with piping for 220v
Water circulation pump with piping for 115v or 480v
VFD for agitator or chocolate pump
Allen Bradley VFD for agitator or chocolate pump
Additional 3kW heater for 1000lb, 2000lb or 3000lb tanks
Upgrade 3kW heater to 4kW heater on 1000lb, 2000lb or 3000lb tanks
Upgrade 3kW heater to 4kW heater on 4000lb or 5000lb tanks
Allen Bradley controllers
Replace hinged lid with fixed lid
Load cells with carbon steel mounts
Upgrade carbon steel load cell mounts to stainless steel
Load cells summing board
Upcharge for customizing tank dimensions
Upcharge for customizing location of stock tank inlets/outlets
Upcharge for tank insulation for 5000lb and smaller tanks is 20% of tank price
Chocolate pump 1.5" in/out with jacketed head

Used Tinsley 5000lb Carbon Steel Chocolate Tank

Used Tinsley 5000lb Carbon Steel Chocolate Tank
- Built new in 2013
- Serial number 13-9295
- Agitator
- Water jacket with electric heaters
- 2" side discharge ports
- (1) with ball valve (1) capped
- 2" center bottom discharge
- Dished bottom
- 3HP 3/60/220v motor
